hkyb-5 container intelligent ac power factor meter
ⅰ description
container intelligent dc power factor meter has a communication interface, digital display window can realize man-machine conversation function control mode through key control. it can measure active power, reactive power, apparent power, power factor, voltage and current. power measurement accuracy: grade 1.0. measurement range of power factor: 0.3~1.0, range of voltage and current: 0.3v-500v, 1ma-5a. transparent panel design.
ⅱ technical specification
1. accuracy: ±0.5%, reading: 5-figure.
2. display: 6-figure red nixie tube display.
3. display parameters: voltage, current, active power, reactive power, apparent power, power factor, current parameter mode.
4. range: voltage-0-500v, current-5a.
5. input signal: voltage-0-500v, maximum display: 499.9v, current-ac 0-5a, maximum display: 4999ma.
6. operating temperature range: 0℃～ 50℃.
7. power supply: ac 220v±10%, maximum current: 50ma.
8. hole size: 43mm×91mm.
9. encapsulation: plastic enclosure.
10. function: rs-485 interface modbus communication, outrange display “ol”display.
ⅲ wiring diagram
iv reference picture
