hkcb-1 training device of piping switch and monitoring
overview
this system is designed according to the requirement of design, laying, maintenance and monitoring training of ship, industrial flow and gas pipeline. this device mainly consists of remote control and operation station, aluminum rack of piping laying, industrial electric valve, air compressor, valve controller and valve opening monitor, etc. the operation method and design theory of this equipment is same as that of the actual pipeline. it can make the local and remote double-direction control experiment of motor operated valve, experiment of valve opening field indication and feedback signal monitoring, experiment of piping switching indication and innovative laying design, experiment of pneumatic metering theory.
