hkyb-1 container intelligent dc ammeter
ⅰ description
container intelligent dc ammeter has a communication interface and manual/auto range, industrial container, accuracy: no less than grade 4. three-gear display, display format of 100v: 99.99 (two decimal points), display unit: v; display format of 10v: 9.999 (three decimal points), display unit: v; display format of 1v: 999.9, display unit: mv. transparent panel design.
ⅱ technical specification
1. accuracy: four-figure, reading: 5-figure.
2. display: 6-figure red nixie tube display.
3. input signal: ac 0-100v, maximum display: 99.99v.
4. range: 1v/10v/100v/, manual/auto switch.
5. operating temperature range: 0℃~ 50℃.
6. power supply: ac 220v±10%, maximum current: 50ma.
7. hole size: 43mm×91mm.
8. encapsulation: plastic enclosure.
9. function: rs-485 interface modbus communication, outrange display “ol”display.
ⅲ wiring diagram
iv reference picture
